Magnesium Ribbon Sacrificial Anode of Cathodic Protection

Basic Info

Model NO.	1
Trademark	YH
Origin	China
HS Code	79040000
Production Capacity	100000pieces/Every Year

Product Description

Magnesium ribbon sacrificial anode

Product Introduction:
Our company`s magnesium anode is made of high purity magnesium according to ASTM B 843-1995 SY/T0019-1997 standard,It is extruded with specific technology,the anode have excellent electrochemical performance,magnesium ribbon anode has flat shape,the length is adjustable ,it is easy to be bent.The product is used for the high resistivity environment,the protection of casing pipe,the pipeline temporary cathodic protection,storage tank and pipeline protection ,anti strong electrical interference grounding grid.

Main features:
convenient adjustment and convenient construction.

The scope of application:
soil, water and pipeline. It is mainly used for local places with a narrow space (such as the casing pipe section) and the soil and fresh water with high resistivity to protect the oil tank in the electrolyte with high resistivity or other steel structures.

Chemical composition

Type	Al	Zn	Mn	Fe	Ni	Cu	Si	Mg
Magnesium, manganese	<0.010		0.5-1.30	<0.03	<0.001	<0.02		Balance
Pure magnesium	<0.010	<0.010	<0.030	<0.002	<0.001	<0.001	<0.010	>99.95
